 Installation Important points
- The pipe must be completely full.
- Do not subject the equipment to magnetic fields.
- The fluid to be measured must be conductive.
 Do not manipulate the equipment from the electronicsÂ
Equipment can be irreversibly damaged by improper handling.
The pipe must always be full of fluid
For a correct measurement, the pipe must be full.
The Magnetic Flow Meter must be installed on the thrust side of the pump (if present)
The flowmeter should be positioned on the thrust side, NOT the suction side of the pump.
Magnetic Flow Meter Installation near valves
Avoid excessive vibrations
Magnetic Flow Meter Do not expose the equipment to magnetic fields
Allowable Reductions
 Installation after choking valve
Magnetic Flow Meter Device Landline Connection
It is extremely IMPORTANT that the flowmeter is grounded with a cable greater than 4mm2 for its correct operation. A poor ground connection will cause an incorrect flow reading.
