Model Number: BSTDB-50 high precision water level sensor
Application: Liquid
Measuring Range: 0.5m~350m
Accuracy: 0.1%FS / 0.2%FS / 0.5%FS
Operating temperature: -20℃~80℃
Protection Grade: Explosion-proof Exia IIC T6 Ga
Resolution: 0.01mm
Working Pressure: ordinary pressure
Output mode: 4~20MA/RS485Modbus
|
Measuring Range
|
Min 0-0.5 Meter Max 0-350 Meter
|
|
Signal output
|
4-20mATwo wire/RS485Modbus
|
|
Pressure Accuracy Tolerance
|
0.1%FS 0.2%FS 0.5%FS
|
|
Pcess Temperature
|
– 20-80℃
|
|
Power Supply
|
24V DC
|
|
Cable
|
PE cable with vents
|
@ Suit for dry and harsh environment
Digital circuit board with Lightning Protection&Anti-static design
@ Suit for high temperature environment(etc: Fire Disaster)
Pouring Sealant make HCDB-30 compatible with medium temperature up to 300°C
@ Available in humid environment
The vent with a filter breath atmosphere and protect moisture enter transducer
@Suit for immersion for more than 10 years in most industrial liquids
@ HCDB-30 waterproof, 6 times sealing process
