Remote Type Electromagnetic Flowmeter
Remote Type Electromagnetic Flowmeter: Supports long-distance monitoring, flexible operation, stable and reliable measurement, enhancing your smart process control.
Enables long-distance monitoring, offers flexible installation, and ensures stable performance.
The Remote Type Electromagnetic Flowmeter is designed for applications requiring long-distance data transmission. Equipped with powerful communication interfaces (such as Modbus, HART), it enables real-time remote data transfer, greatly enhancing operational flexibility. No need for frequent access to the instrument location, ideal for complex or hazardous environments. Its sturdy structure and stable performance ensure accurate and reliable flow data under various conditions, providing a solid guarantee for automation and remote monitoring.
Features:
- Long-Distance Transmission: Supports multiple communication protocols for extended data transfer range and real-time monitoring.
- Flexible Installation: Separated remote sensor and controller, easy to install in hard-to-reach or hazardous areas.
- Stable & Reliable: High-quality materials and anti-interference design ensure long-term stable operation.
Technical Specifications
| Product Model | BST |
|---|---|
| DN Range | DN3~DN3000mm |
| Accuracy Class | 0.2%, 0.5%, 1.0% |
| Measured Media | Pure Conductive Liquids, Conductive Liquids with Impurities, Low-viscosity Clean Liquids, High-viscosity Liquids, Highly Corrosive Liquids, Cryogenic / High-temperature Liquids, Solid-Liquid Slurry, Pulsating Flow, Volatile Liquids |
| Nominal Pressure | 0.6Mpa, 1.0Mpa, 1.6Mpa |
| Liner Material | Polytetrafluoroethylene PTFE |
| Electrode Material | 316L stainless steel, Hastelloy B, Hastelloy C, tantalum, titanium platinum, nickel |
| Housing Material | Carbon Steel |
| Connection Method | Flange Connection, Threaded Connection, Clamp-on Type |
| Power Supply | DC 3.6V Battery, DC12-36V, AC 220V, AC 265V |
| Output Signal | Pulse, 4-20mA, RS485 |
| Communication Protocol | Standard MODBUS Protocol, Hart Protocol |
| IP Rating | IP65, IP67, IP68 |
Market Applications
Mining & Others
In the Mining and Metallurgy sectors, media primarily consist of heavy, abrasive mineral slurries, tailings, and corrosive leaching acids. These substances are characterized by high...
Chemical
In the Chemical sector, media range from aggressive acids and alkalis to volatile organic solvents and complex polymers. These fluids are characterized by extreme corrosivity,...
Food & Beverage
The Food & Beverage industry is a core livelihood industry, providing accurate metering guarantee for the processing and transportation of various food and beverage media.
Oil & Gas
In the Oil & Gas industry, media range from viscous crude and lubricants to highly compressible natural gas and liquefied fuels. These substances are typically...
Pharmaceutical
The Pharmaceutical industry is a core industry ensuring public health, providing accurate metering support for various media in the entire pharmaceutical production process.
Power
The Power industry is a pillar field of the national economy, providing accurate metering support for media in power generation, transmission and thermal energy transportation...
Pulp & Paper
The Pulp & Paper industry is a core field of basic industry, providing accurate metering support for the processing and transportation of pulp, slurry and...
Water & Wastewater
The Water & Wastewater industry is a core field of water resource management, providing accurate metering support for water medium transportation and treatment.
